Architectural Glass

MARUNI TEMPERED GLASS

Specification

Thickness               : 4mm-19mm
Maximum Size      : 2500mm x 6500mm
Temperable Low-E Glass (Emissivity Value 0.04%)

Maruni Tempered Glass is processed by heating glass to its transition stage (610-650 degrees Celsius), and then cooling it rapidly with blasts of air through specially designed air nozzles. This gives the glass high surface stress and tensile strength and it becomes four to five times stronger than annealed glass of the same thickness.

Benefit:
  • Maruni adopts the Tam Glass (Glasston) horizontal tempering process.
  • Once breakage occurs, the glass disintegrates into small cubical fragments
    which are relatively harmless to human body
  • It withstands abrupt change of temperature. For example, a piece of 5mm
    tole-rates the temperature variations within the range of 200°C
  • Tempered glass should undergo heat soak to improve safety in use
Applications

For Building
Interior and Exterior
All Glass Entrances and Storefronts
High Rise Windows
Frameless Doors
Showers and Toilet Cubicles
Staircase Handrails
Handrails/ Balustrades

For Industry
Table Tops
Glass Showcases
Elevator Panels
Escalator Side Plates
Automotive, Train, Vessel
Refrigerator Trays
Microwave Glass Panels

architectural-1

MARUNI HEAT STRENGTHEN GLASS

Specification

Maximum Size      : 2500mm x 6500mm

Heat Strengthened glass, due to the special process it goes through, has high impact and shock resistance properties and is at least two times stronger than annealed glass. Due to its medium tensile strength it is very safe as it does not fall from its frame even if it breaks, making it ideal for use in glazing. It is also capable of withstanding temperature differences up to 20 degree Celsius on its surface. While its medium surface stress makes it resistant to scratches, sudden impacts, shocks and wind pressure during storms. Heat strengthened glass is very popular among the professional designers due to all these properties.

Additonally, this process also dishmishes the probability of glass spontaneous breakage caused by Nickel Sulfide (Nis).

architectural-2

MARUNI BENDING TEMPERED GLASS

Specification

Maximum Size      : 2400mm x 4200mm

Maruni Glass has introduced Bending and Tempering system, a horizontal bending and tempering glass processor. Exceptional technology adjusts the bending radius and control system parameters to achieve cylindrical and curved glass shapes. The glass is heated to the correct temperature in the precisely controlled furnace, which eliminates glass waviness as a result of overheating and ensures an outstanding glass quality.

Benefit:
  • 3-5 times harder than bending glass
  • No tong marks on the glass
  • Horizontal bending and tempering method ensures stable product quality
  • Both sides of the curved glass surfaces can achieve outstanding quality
  • Exceptional optical quality is especially prominent in bending tempered reflective glass
Applications

For Building
Interior and Exterior
Curved Windows
Curved Railings
Curved Skylights
Curved Canopy

For Industry
Curved Windows
Curved Railings
Curved Skylights
Curved Canopy

architectural-3

MARUNI OPTIMUS GLASS

Specification

Maximum Size: 2700mm x 5000mm

Optimus is an energy-efficient glazing system, with excellent thermal insulation and noise reduction. It is made with two or more plies of glass, separated by a spacer that is filled with desiccant to isolate glass. At the same time, hollow portion is filled with dry air or inert gas and sealed with butyl rubber, poly sulfide rubber and structural adhesive to ensure is air tight. It is possible to combine Optimus with tempered glass, heat-strengthened glass, laminated or even curved glass. However, for higher performance glass Optimus is best suited with combination of Low-E Glass.

Benefit:
  • Optimus is of flawless quality with high degree of resistance to heat, retarding the flux of heat during the summer and heat loss during winter. It saves electricity being used for heating or cooling by decreasing air to air heat transfer. The air enclosed within the insulated glass panes makes insulating capability twice that of monolithic glass. Therefore load of air-conditioning is greatly reduced, with insulating glass; the insulating effect of air layer makes it tough for the glass to become cold and is relatively difficult for dew condensation.
  • Optimus is made of two or more glass panes, which can be of any type as per  customer’s requirement, separated by aluminium spacers’.
Applications

For Building
Windows
Glass Walls
Sound Studio Room
High Performance Building
Facades

For Industry
Ovens
Refrigerator Doors
Liquor Cabinet
Beverage Display Cabinet
Disinfection Cabinet

architectural-4

MARUNI HEAT SOAK

Specification

Thickness               : 4mm-19mm
Maximum Size     : 2500mm x 5500mm

Maruni Heat Soak Treatment employs the heat soak testing system to detect the occasional occurrence of nickel sulfide (Nis) inclusions in tempered glass. Under strictly controlled temperatures, high-temperature β-Nis converts to low – temperature β-Nis which accompanies a 2-4% expansion in volume and causes the glass to break if the inclusion is located at a tensile stress. The test reduces the frequency of spontaneous breakage of tempered glass after installation. Tempered glass is heat-soaked for 2-8 hours (†2) at a constant temperature of 290°±10° and then allowed to return to room temperature over a specified time.

Benefit:
  • Reduces risks of spontaneous breakage of tempered glass.
  • Increase strength and safety.
  • Reduces potential public liability
  • Low cost compared to glass replacement costs
  • Heat soak treatment glass carries a replacement warranty
Applications

All tempered glass should undergo heat soak treatment

architectural-5

MARUNI LAMINATED SAFETY GLASS

Specification

Maximum Size      : 2500mm x 5000mm

The polyvinyl film used in Maruni laminated glass is clear and reliable. It does blister or in any way disturb the total clarity of the glass sheets. This superb Polyvinyl Butryal (PVB) films are manufactured by world renowned PVB makers: Dupont, Solutia and Trosifol.

All these outstanding features make Maruni laminated safety glass the perfect product whenever a safety glazing materials are needed. Maruni Laminated Safety Glass is  a high safety glass. And laminated glass does not break as ordinary glass does. It absorbs all impacts and remains intact even after breaking.

Benefit:
  • Safety: When the laminated glass is installed on buildings that suffer external force, even the glass breaks, it still keeps at the original frame. What’s more, the people inside and outside of building will avoid the damage of splash glass fragments
  • Anti-hurricane and earthquake: Although the glass breaks, it still remains in place not fall entirely to the ground
  • UV: It can cut of hugely ultraviolet from sunlight. Blocking ultraviolet rate is above 99% to avoid the ultraviolet radiation so that it prevents valuable artwork, carpets and furniture from discoloration
  • Noise Reduction: PVB film has barrier and absorption effect on soundwave, thereby reducing the noise

architectural-6

MARUNI ULTRA SAFETY GLASS

Specification

Total Thickness  :  60mm

Triple Laminated Glass consists of three layers of glass with a layer of plastic film in between each between each glass to which the glass adheres. The laminated glass can be manufactured using regular glass or toughened glass depending on the application. Regular triple laminated glasses are suitable for applications which require higher factor of safety such as security windows, flooring, staircase, etc.

Triple Strengthened Laminated Glass consists of three layers of glass with a layer of pvb and strengthened interlayer in between. This interlayer increases the tensile and elastic strength, delays intrusion and hence represents an effective barrier. The strengthened laminated glass can be manufactured using regular glass or toughened glass depending on the application. These are suitable for applications which require higher factor of safety such as crime prevention glass, bulletproof glass, etc.

Triple laminated bending Glass consists of three layers of glass with a layer of plastic film in between each between each glass to which the glass adheres. The triple laminated bending glass can be manufactured using regular glass or toughened glass depending on the application. Triple bending laminated glasses are suitable for applications which require higher factor of safety glass such as curved glass wall, curved railing, etc.

architectural-7

MARUNI DIGITAL CERAMIC FRIT GLASS

Specification

Maximum Size: 3800mm x 8000mm

The  great possibilities of architectural design are now even more possible. Digital Ceramic Frit by Maruni combines the durability of ceramic inks with the versatility of digital printing into one proven solution for all glass-printing applications. A stunning new technology that’s as beautiful and imaginative as it is functional.

Benefit:
  • Easy to Clean
  • Weather Resistance
  • Scratch Resistance
  • Permanent Printed Color
  • Resistance to Moisture, Oil, Soap, Detergent, Chemicals
  • 3-5 Times Stronger Than Annealed Glass (Tempered)
Applications

For Building
Facades
Skylights
Partitions

For Industry
Bus Windshield
Writing Board
Furniture Glass
Table Top

architectural-8
header-furniture-glass

Furniture Glass

RESIDENTIAL GLASS TOPS

Exclusive and modern, traditional or contemporary, Maruni Glass table tops can accent any space. While our table tops are functional pieces, they are also works of art that today add a touch of elegance to living rooms, dining rooms, bedrooms TV rooms, patios, and kitchens all around the world. Maruni Glass glass is used in a variety of decorative furnishings including dining or breakfast tables, end tables, sofa tables, coffee tables, outdoor tables, and for the construction of desks, bookcases, and glass racks.

Our offers more than a dozen standard table top designs, but, regularly creates table tops from designs that originate from the customer’s imaginations. Thick glass table tops can be cut to any size and shape. Frosted and etched patterns in thousands of designs provide individuality to every glass top with unmatched quality. Once cut, they can be etched, beveled, or decorated to any specification. For quality, selection, and value in residential furnishings, Maruni Glass is a world apart.

  • Dining Table
  • Coffee Table
  • Patio Table
  • Cupboard
  • Glass Shelves
  • TV Stands
  • Doors
  • Window
furniture-1

COMMERCIAL GLASS TOPS

Maruni Glass table tops are “clearly the top choice” for decorative commercial furnishings. Today they lend an air of functional elegance to offices, conference rooms, and reception areas creating an atmosphere of professionalism and success in thousands of businesses, large and small. While Maruni Glass offers more than a dozen standard table top designs for commercial use, the company routinely customizes business furnishings to fit any space imaginable.

Maruni Glass thick glass table tops can be hand crafted in any size and shape. Clear glass with frosted or etched company logos gives that particular corporate image a company requires. Once cut, the table tops can be etched, beveled or decorated to fit any customer specifications. Whether the finished product is a small waiting room end table designed to support a lamp or an imposing conference table around which weighty financial decisions will be made, Maruni Glass leads the industry in quality, selection, and value.

  • Work Table
  • Coffee Table
  • Conference Table
  • Cabinet
  • Doors
  • Window
furniture-2

CUSTOM ORDERED GLASS

If you don’t like something from our standard product line, we can create anything you can imagine. Our engineers, designers, and product development personal can take any idea and turn it into reality. The customer design capabilities of Maruni Glass are truly limitless. To complecument our expert technical capabilities we offer the finest customer service. Every account is assigned a customer service representative to work with you from concept of product development, scheduling, shipping, and delivery. You simply cannot get better products – or better customer service. At Maruni Glass, one call answers all.

furniture-3

GLASS TOP DESIGN

Maruni has various table top glass, it is avalable in 4 basic shapes but also can be orderered accustomed to your needs.

furniture-4
header-glass-options

Glass Options


CNC CUTTING & DRILLING

This service is usually provided for the large scale, high volume projects.

It has two outstanding benefits :

  • Material efficiency. Preceded by careful calculations, an optimizing
    program will be created to help confine material wastage, which, at
    the end, ensures more competitive prices.
  • Precision cutting, since the process utilizes automated machines,
    which are computer controlled.


options-1

CNC CUTTING

options-2

DRILLING


EDGING

This process shapes the thick edges of the glass / mirror:

  • Thickness 3 – 25 mm
  • Minimum Size 40 x 40 mm
  • Maximum size up to 600 kg of weight

Sophisticated and modern machinery ensure perfect shapes, in terms of dimensional accuracy, rectangularity, smoothness and quality of the profiles.

For glass/mirror of difficult shape, a CNC machine will be utilized, which reduces the workable size to 3,000 x 2,200 mm.


options-3

Examples of this application are :
Cabinet glass door
Furniture shelf
Dining table
Coffee table
Frameless glass door
Shower glass


options-4

Waterfall Edge

options-5

Bullnose Edge


BEVELLING

Applicable for the following dimensions :

  • Thickness : 3 – 25 mm
  • Minimum size 40 x 40 mm
  • Maximum size up to 600 Kg of weight

The sophisticated and modern machinery ensures perfect bevels along every side,
as well as smoothness and physical conformity of each batch. CNC (computerized
numerical control) machine will be utilized, which reduces the workable
size 3,000 x 2200 mm.

For glass/mirror of difficult shape, a CNC machine will be utilized, which reduces the workable size to 3,000 x 2,200 mm.

Examples of this application are :
Decorative Mirror
Cabinet- glass door
France- glass door
Dining Table
Coffee Table
Office Table


options-6
options-7

SANDBLASTING

Hot Glass Design products can be sandblasted
to give a frosted/etched effect to the glass.

Sandblasting can be done to the smooth or textured side of the panel. All our sandblasted glass panels are “CLEARSHIELDtm” coated. Creating a non-stick easy to clean surface, which is chemically inert to most substances. Resists staining by finger marks etc. – Preserving it’s beautiful appearance.

Sand Blast Textures
All textures are available in 6 and 10mm Toughened glass or 6.4 Laminate in accordance with safety requirements to B.S.6206 Class A.

Examples of this application are :
Glass partitions for corporate offices
Balustrade Glass
Store Signage
French Door Glass
Tempered Glass Doors
Store Fixture Shelves
Large hotel or casino glass projects


options-8
options-10
options-9

V-GROOVE GLASS

V-Grooving – by utilizing CNC equipment V-groove glass may be produced to replicate any design. V-grooved glass may be used in exterior doorlites, interior French or Patio doors. Glass grooving is not an edging process, but uses similar polishing and grinding technology in producing decorative grooves (patterns) or plate grooves (straight) on the surface of glass. The depth of the groove is related to the thickness of the glass, and it is not recommended to be fabricated on glass less than 1/8″ thick.

The Brilliant Cutting Process

Brilliant cutting, the process of wheel engraving sheets of plate glass, was first introduced to this country during the 1850s by Mark Bowden of Bristol. There was nothing inherently new about the technique; the process of engraving hollow-ware glass and mirrors was an old established craft. Its application on flat glass however, was confined to a comparatively small scale. The proliferation of cast glass in the 19th century provided the opportunity to apply this craft on an architectural scale.

Brilliant cutters used engraving wheels made from carboniferous sandstone that varied in diameter from 5 to 90cm. Each stone created a particular effect. Generally the large stones were used for straight lines and gentle curves and the smaller stones for tighter curves. The profile of the cutting edge was either round, square or mitred.


options-11
options-12
options-13

Sand Blast Textures
Round profiled wheels produced a concave effect and were often used to produce a circular or elliptical concavity in the glass known as a punt

options-14

Square profiled wheels
were used mostly for line work and for making leaf forms. Only one side of the wheel was used, which resulted in a groove that was deep on one side and gradually sloping off to nothing on the other. In the case of curves the deep side was on the inner side of the arc. Ogee curves therefore presented a difficult challenge as the worker had to change from one side of the wheel to the other and skilfully splice the two cuts in a way that did not interfere with the design

options-15

Mitre profiled wheels
made a ‘V’ shaped cut


Cutting wheels were lubricated with water and were run on a shaft supported by a wooden or iron frame. Small glass sheets were hand-held over the cutting wheel, while large sheets were held in a sling suspended from a counterbalanced beam on the ceiling above the cutting lathe, allowing the craftsmen to manage them with ease whilst engraving the design.

Once the design was engraved to the correct depth, the cuts were then smoothed and finally polished. Smoothing was done in a similar way to engraving using willow wheels and ground pumice. These wheels had to match the profile of the cut. Once smooth, the cuts were polished with a revolving fibre brush impregnated with a polishing compound, usually rouge.

Brilliant cutting was (and still is) a highly skilled and labour-intensive process. Each cut required a different wheel and sometimes these had to be custom-made to suit the particular job in hand. However, the process did not always stop there. With the exception of flashed glass (see the first illustration, top of page), most brilliant cut work had a frosted background. If this was to be of a single tone the sheet was usually mechanically abraded using emery flour in a process akin to ’emboss and ground’ (see above). Frequently though, brilliant cut sheets were acid embossed either with a clear etch or white acid and triple emboss. Areas of the design were sometimes gilded and often the whole sheet was silvered to produce a decorative mirror.

The Victorians’ delight in decorative richness has not been shared by subsequent generations who judged it to exceed the bounds of good taste. There were many poor examples of the craft, as there were in all the trades, but at their best, brilliant cutting and acid etching combined both originality and excellence in design and craft. Regrettably precious few examples have survived to the present day.



FIGURED GLASS

Also known as “patterned” or “ornamental” glass, figured glass is generally produced by the rolling process (see “rolled glass”). The surfaces of the rollers used carry the pattern or design to be “imprinted” in the glass as it passes between them. The process gives the glass a textured surface on one or both sides. The surface finish may be both decorative and functional. Apart from the huge variety of patterns possible, figured glass can also offer light dispersion and glare reduction characteristics.

options-16

header-decorative-glass

Decorative Glass & Mirrors

header-standard-products

Standard Products


STANDARD DOORS

Door and Entry Assemblies

Frameless glass doors and associated panels such as sidelites and highlites must be a minimum of either 10mm or 12mm toughened safety glass.


standard-1

FRAMELESS DOORS

Standard size for frameless door
2010 X 900 X 12MM

standard-2

SHOWER DOORS

Standard size for shower door 2010 X 800 X 10MM,
for shower enclosures :
• 90 X 210 X 10MM
• 90 X 200 X 10MM
• 65 X 200/210 X 10MM


GLASS THICKNESS

MINIMUM GLASS THICKNESS TO MAXIMUM DOOR LEAF HEIGHTS

Size (mm)
10
12
12
15
19

Internal door height (mm)
2100
2700
2700
3100
3500

External doorheight (mm)
2100
2300
2600
As per AS1288
As per AS1288

Max wind pressure (kPa)
0.65
1.00
0.65
As per AS1288
As per AS1288



FITTINGS

Frameless glass doors can be installed with rails and/or patch fittings as per Type A, B, C or S and come in a variety of finishes including anodised, powder coated, plated brass and stainless steel finishes. Marine grade stainless steel is recommended for where the air has a high salt content.



HANDLES

Standard handles are usually ‘D’ shaped back to back, 32mm diameter handles, 300mm in length. The standard finish is satin stainless steel. A wide range of alternative lengths, shapes and colours are available on request.

HEAVY WEIGHT GLASS AVAILABILITY CHART

Glass Type
Clear
Grey
Bronze
Green

Thickness (mm)
10,12,15,19,25
10,12
10,12
10,12*


standard-3
standard-4

TABLE TOP

Maruni carries in stock the following table tops. If your size is not shown, please contact us. Special orders are always welcome.

Diameter
36″
42″
48″
54″
60″
42″
48″
54″
60″
42″ x 72″

Thickness
1/2″
1/2″
1/2″
1/2″
1/2″
3/4″
3/4″
3/4″
3/4″
3/4″

Finish
Pencil Polish
Pencil Polish
Pencil Polish
Pencil Polish
Pencil Polish
1″ Bevel
1″ Bevel
1″ Bevel
1″ Bevel
1″ Bevel


standard-5
standard-6
